Suitable For Appliance Logistics Swivel Wheel Sorter Lowers Overall Operational Costs
The Swivel Wheel Sorting Machine, often referred to as the Divert Wheel Sorter or Rotating Wheel Sorter, is a state-of-the-art solution designed for the efficient sorting of parcels and cartons in conveyor systems.
This machine integrates an electric drum (wheel), a steering mechanism, a control unit, and a robust frame. It operates by rotating the electric drum to move items, with servo motors and steering modules adjusting the drum's angle to divert items left or right. The Swivel Wheel Sorting Machine can handle various packaging types, including cartons up to 50kg, waterproof bags, woven bags, and flat-bottomed non-standard packages. With a sorting speed of 2m/s, it can process up to 6000 items per hour, making it perfect for applications in postal services, express delivery, e-commerce logistics, and distribution centers.
For further information about the Swivel Wheel Sorting Machine, please consult the product description below or contact our customer service representatives at Realkey.
Product Features
Technical Parameters
| Model | SWS-10M | SWS-12H |
| Sorted Items | Medium to large parcels, woven bags, flexible packages, etc. | |
| Weight Range | 0.2kg≤M≤50kg | 0.2kg≤M≤50kg |
| Sorting Capacity | 4000 pieces per hour | 6000 pieces per hour |
| Parcel Size Range | MAX:1000*1000*700mm | |
| (Example for a 1-meter wide device) | MIN:150*150*30mm | |
| Sorting Success Rate | 99.99% | |
| Sorting Modes | Single-sided sorting / Double-sided sorting | |
| Electric Drum Size | Drum length 85mm * Drum diameter 70mm | |
| Conveying Speed | 1-1.5m/s | 1.2-2m/s |
| Number of Swing Mechanisms | Not less than 2 | Not less than 5 |
| Parcel Spacing | 800mm | 400mm |
| Operating Noise | ≤72dB(A) | |
Product Features
Versatility
The swing wheel sorter features a flat surface made up of several small electric rollers. These rubber-coated rollers provide a broad area of flexible contact with the bottoms of items, ensuring a seamless and effective sorting operation. This design is particularly advantageous for handling a range of parcels, clothing, books, boxes, cartons, and soft packages.
Efficient Sorting
Utilizing electric rollers as its main conveying medium, the swing wheel sorter offers numerous benefits such as high load capacity, low noise, rapid speed, and smooth operation. By eliminating complex transmission mechanisms found in traditional systems, the swing wheel sorter enhances efficiency, achieving sorting rates of up to 6000 pieces per hour.
Compact Structure
The swing wheel sorter is distinguished by its straightforward design, stable framework, and minimal failure rates. The steering components are linked via articulated bearings, allowing for fine-tuning of the steering angle based on operational needs. Servo motors supply the steering power, ensuring quick responsiveness and smooth sorting processes. Each machine is equipped with multiple independent steering modules that operate based on sorting signals.
Quick Installation and Removal
Both the single-group swing wheel and the single-row module of the swing wheel sorter utilize a standardized, modular design. The independent modules for conveying can be easily taken apart from the transmission components, enabling hassle-free disassembly and maintenance.
Application
The swing wheel sorter is optimized for an efficient sorting process, making it ideal for handling various types of parcels, clothing, books, boxes, cartons, and soft packages. It is widely applied in logistics settings, including express delivery services, logistics hubs, and warehouses. In these environments, the swing wheel sorter can swiftly and accurately sort express parcels and goods.
In e-commerce warehouses, the swing wheel sorter significantly enhances the speed and efficiency of processing numerous orders and parcels. This capability has made it a popular choice in e-commerce logistics. Furthermore, in manufacturing production lines, the swing wheel sorter aids in effectively managing raw materials and components, facilitating organized categorization and storage. Its applications extend to sectors like healthcare, food production, and renewable energy.
Advantages
Advanced Technology
The Realkey swing wheel sorter employs a sophisticated control system integrated with sensors to manage equipment operation based on package arrivals, ensuring optimal efficiency and energy conservation. The servo-driven sorting mechanism guarantees rapid response times and precise control over turning angles. Various sorting modes, including uni-directional, bi-directional, and multi-angle sorting, are available to cater to specific user needs.
Precision Manufacturing
All components are produced using CNC precision machining, leading to meticulous assembly and fine-tuning. This results in equipment characterized by high accuracy, extended lifespan, low noise levels, and minimal maintenance costs.
Safety and Stability
The Realkey swing wheel sorter is built to be durable and reliable, meeting advanced domestic standards for stability. Comprehensive protection measures are integrated into all operational components, and thoughtful safety designs alleviate concerns for operators.
Reliability
With 17 years of experience in logistics conveyance and automated sorting, Realkey excels in providing sorting solutions tailored to customer needs. Our products are known for their robust durability, establishing us as a reliable partner you can trust.
